Name: Custom Series BETA Modern LED Street Light Manufacturers Suppliers Factory - Made in China
Brand: BERSN
SKU: 244294284

BETA Series Modern LED Street Light are a new series launched by Bersn in 2021.Mainly used in streets, parking lots and any other open areas that require a lot of light, it can provide the lighting you need in any environment.

Send Inquiry

Product Introduction

Competitive Led Road Light

BETA Series

Unrivaled Efficacy 160 lm/W

Since its launch in 2021, the BETA series street lights have been selling well with their excellent quality, good performance and favorable prices. The product adopts high-quality LED chips and high-transmittance PC optical lenses, with a luminous efficiency of up to 160lm/W.

https://www.bersn-smartlighting.com/smart-street-light/smart-city-streetlighting.html

product-1822-900

Product Features

Wattage range: 30-180W
Max efficiency up to 160lm/w
IP66 and IK10
Good quality and reasonable price
10 /20KV surge protection
Smart design, low transportation costs
Excellent Light Distribution and Uniformity
ENEC, CE, certified.
Smart Control: 1-10V/ DALI dimming, NEMA, Zhaga, Photocell, Motion sensor, Lora socket for smart control system or future updating

Products specification

Series No	BETA Series Led Road Lamp
Power	30W, 50W, 60W, 80W, 100W, 120W, 150W,180W
Efficacy	160lm/W
Input Voltage	100-240/277 VAC, 50 / 60 Hz
Power Factor	>0.95
Surge Protection	10KV (Default) / 20KV (available on request)
IP Rating	IP66
IK Rating	IK08 / IK10
CCT	3000K, 4000K, 5000K, 5700K
CRI	Ra>70 (Default) / Ra>80
Operating Temperature	-40°C to + 50°C
Beam Angle	Type II/III-S/M
Mounting Option	Side entry or Vertical pole mounted ( with extra adapter)
Warranty	3Years
Certification	ENEC, CE, CB, Zhaga-D4i, ROHS, LM79, LM80, LM82, LM84, TM-21, ISTMT, IEC62471/62778
Control	Photocell, NEMA Socket 3P/5P/7P / Zhaga Socket, Motion Sensor, Timing Dimming, 1-10V Dimmable, Zigbee or LORAMesh control
Body	Die-cast Aluminium
Cover	Tempered Glass
Optic	PC Len
LED	TYF 5050
Mount Hole	ɸ60 / ɸ50 / ɸ40

Certifications

As a professional manufacturer of LED street lights, our LED street lights have rich certification and test reports, such as , CE, ROHS, IK08. IP66 and so on

CE-EMC IEC 55015

CE-EMC IEC 61000-3-2

CE-LVD EN 60598-2-3

CE-LVD EN IEC 62031

ROHS IEC 62321-3-1

IP66 IEC 60598-1

Best LED Street Light Manufacturer, Factory,and Supplier In China

We have been a LED street light manufacturer, factory and supplier in China since 2001. The factory has passed ISO9001, ISO1400 certification. With a professional engineering team, we are very good at designing, producing and developing various high-quality street lights.
Please feel free to consult all questions about street light projects. We will provide free road lighting design, best products, best services and prices you like.

CERTIFICATES

Our led street lights are CE, RoHS, IP66, IK08and approved, and our factory ISO9001, ISO14000, certified.

BEST QUALITY&PRICE

We use top stable quality led driver and chips like Philips driver and chips for all road lights. Providing 3Years warranty at the cheapest price.

OEM/ODM/SKD

Available to do OEM/ODM/SKD for all streetlamps. No MOQ limits for led streetlights retailers, wholesalers, and engineering companies.

Product Display

1. Design and planning

Functional design: Determine the basic functions of LED street lights, such as lighting requirements, power requirements, beam angle, etc.
Appearance design: Design the shape, size and material of the street lights to ensure good heat dissipation and durability.

2. Raw material procurement

LED chips and lamp beads: Select high-brightness and high-efficiency LED chips to ensure light efficiency and life.
Heat dissipation materials: Purchase heat dissipation materials, such as aluminum alloy or thermal conductive glue, for effective heat dissipation and increased LED life.
Electronic components: Purchase necessary electronic components such as drive power, control circuit and optical lens.

3. PCB design and manufacturing

Circuit design: Design LED drive circuit and control circuit according to design requirements.
PCB manufacturing: Design and manufacture circuit boards (PCBs) for LED street lights, install LED chips and electronic components.

4. Assembly and production

LED chip installation: Solder LED chips and other electronic components to PCB.
Lamp assembly: Install the PCB with LED chips and electronic components into the designed housing.
Electrical connection: Connect the drive power supply and control circuit to ensure normal electrical operation

5. Optical system debugging

Lens installation: Install and adjust the optical lens to control the beam angle and light distribution of the LED.
Optical performance test: Perform optical performance test on the lamps to ensure that the beam angle and brightness meet the design requirements.

6. Testing and quality inspection

Functional testing: Perform functional tests on assembled LED street lights, such as switching, dimming, stability, etc.
Life testing: Perform long-term stability and life testing to ensure that LED street lights maintain stable performance during long-term use.

7. Packaging and delivery

Product packaging: Design and make packaging boxes and logos for LED street lights.
Delivery: Arrange the delivery and transportation of lamps to ensure that the products are not damaged during transportation.

8. Marketing and after-sales service

Marketing: Promote LED street lights to the market through various channels to meet the needs of different customer groups.
After-sales service: Provide after-sales support and maintenance services to ensure customer satisfaction and continued use of products.

Size

Installation

FAQ

Q: What is an LED street light?

A: LED street lights are street lights that use LED light-emitting diodes (SMD LEDs) as light sources. They have the advantages of good light directionality, low power consumption, good driving characteristics, fast response speed, strong shock resistance, long service life, and environmental protection.

Q: What is the general installation height of the LED Road Light?

A: Generally, street light poles are available in 3m, 4m, 5m, 6m, 8m, 10m, 12m, and 14m heights. You can choose poles of different heights according to your own design.

Q: Why Choose High Efficiency Led Parking Lot Light ?

A: LED floodlights are very energy-efficient, consuming far less electricity than traditional light sources. LED lights have a longer lifespan, reducing maintenance frequency and replacement costs. Low power consumption maximizes energy savings.

Q: Why Led street lights are environmentally friendly?

A: LEDs help reduce carbon emissions and energy consumption. By switching to LED lights, cities can significantly reduce their carbon footprint and contribute to a cleaner, greener planet.

Q: Why Led Street Lights Are More Durable and Reliable?

A: LED street lights are made of high-quality materials that are resistant to corrosion, moisture, and extreme temperatures. This increases the lifespan and reduces the need for frequent maintenance and replacement. LED lights also feature instant-on, eliminating the warm-up time required for traditional lamps.

Q: What is the Importance of Street Lights in Rural Areas?

A: Streetlights are crucial in rural areas to enhance safety at intersections, significantly reducing night-time crashes. Installation offers a cost-effective strategy with a 15 to one benefit-cost ratio. Streetlights are crucial for safe transportation in rural areas.

Q: What is the recommend color temperature for modern led street light?

A: For LED road lighting, generally 2800-3200K Warm white,4000-4500K daylight, 6000-6500K cold white options.

Q: What is the purpose of street lights?

A: Street lighting provides a number of important benefits. It can be used to promote security in urban areas and to increase the quality of life by artificially extending the hours in which it is light so that activity can take place. Street lighting also improves safety for drivers, riders, and pedestrians.
