AURORA 30W 0.4-0.9A AOC 100-277V 0-10V DIM
30W 50W 60W 80W 100W 120W 150W 200W 250W 300W 36V 48V IP67 Level 0-10V Dimmable LED Driver for Led Street Light
Features
• Adjustable output current for flexible adjustment of output current for products with different specification.
• AC input range (160-305 Vac), withstand 380V voltage input protection.
• Built-in active PFC function.
• Protection: Short circuit/ Over current/ Over voltage/ Over temperature.
• IP67 design for outdoor installation.
• Surge Protection: L/N-G 6kV, L-L 4kV.
• 5 years warranty.
Applications
LED Street Lighting
LED high-bay Lighting
Packing space lighting
LED fishing lamp
LED green house lighting
Type '''HL'' for use in Class I, Division 2 hazardous (Classified) location
Electrical Input Data
Specification item | Value | Unit | Condition |
Nominal Input Voltage | 100…277 | Vac | |
Operation Voltage AC | 90…305 | Vac | Safety operation |
Nominal Input Frequency | 50…60 | Hz | |
Input Frequency AC | 47…63 | Hz | Maximum permissible range |
Nominal Input Current | 0.11…0.32 | A | 100V…277V atfull load |
Maximum Input Current | 0.38 | A | At 90V |
Nominal Input Power | 34 | W | At 230V at full load |
Power Factor | ≥0.92 | At 230V at full load | |
Total Harmonic Distortion | ≤15 | % | At 230V at full load |
Efficiency | 88 | % | At 230V at full load |
Electrical Output Data
Specification item | Value | Unit | Condition |
Regulation Method | Constant Current | ||
Output Voltage | 28…42 | Vdc | |
Output Voltage Max | 48 | Vdc | Peak voltage at open circuit |
Output Current | 0.4-0.9 | A | AOC |
Output Current Tolerance | ±5 | % | At max. output current, Ta=25 oC (cold start) |
Output Current Ripple LF | 5 | % | Ripple = peak / average, at<1kHz |
Output Power | 30 | W | At full load |
Galvanic Isolation | Yes | Double; 3750V |
Operational Temperature and Humidity
Specification item | Value | Unit | Condition |
Ambient Temperature | -40…+55 | °C | |
Tcase Maximum Tcase | 85 | °C | Measured at Tc-point |
Tcase Life | 70 | °C | Measured at Tc-point |
Tcase Cut-Off | 90 | °C | Cut-off |
Lifetime
Specification item | Value | Unit | Condition |
Lifetime | 50,000 | Hours | At Tcase Life; Survival rate = 90% |
Programmable Features
Specification item | Value | Remark | Condition |
Adjustable Output Current (AOC) | 0.4-0.9A | ||
Dimming | DAC 0-10V |
Features
Specification item | Value | Remark | Condition |
Over Temperature Protection | Yes | Cut-off | |
Open Circuit Protection | Yes | ||
Short Circuit Protection | Yes | ||
Over Power Protection | Yes |
Certificates and Standards
Specification item | Value |
Approval Marks | ENEC / CE / RoHS |
Ingress Protection Rating | IP67 |
Surge Capability
Specification item | Value | Unit | Condition |
Mains Surge Capability Differential Mode | 4 | KV | L-N |
Mains Surge Capability Common Mode | 6 | KV | L/N-GND |
Specification item | Value |
Product Name | AURORA 30W 0.4-0.9A AOC 100-277V 0－10V DIM IP67 |
Model No. | BS-H30-42D |
Pieces per Box | 10 |
Related Models
Model | Maximum output power | Output Current | Output Voltage | Power factor | Dim | Dimension |
BS-H50-36 | 50W | 1.1-1.5A | 36v | 0.9 | Yes | 130*44*34mm |
BS-H60-36 | 60W | 1-1.8A | 36v | 0.9 | Yes | 130*44*34mm |
BS-H80-36 | 80W | 1.-2.8A | 36v | 0.9 | Yes | 130*44*34mm |
BS-H100-36 | 100W | 1.3-3A | 36v | 0.9 | Yes | 216*73*42mm |
BS-H120-36 | 120W | 1.6-3.3A | 36v | 0.9 | Yes | 216*73*42mm |
(Compared to traditional lighting products such as high-pressure sodium lamps, mercury lamps, etc.) Advantages:
Energy-saving and efficient: LED drivers have high light efficiency and low energy consumption, and can save a lot of energy compared to traditional lighting products.
Long life: LED drivers usually have a long life, up to tens of thousands of hours, reducing the frequency of lamp replacement and lowering maintenance costs.
Environmental protection: LED drivers do not contain harmful substances such as mercury, and can effectively reduce carbon dioxide emissions and meet environmental protection requirements.
Rich colors: LED drivers can change color and brightness by adjusting current, providing more lighting options.
Strong durability: The LED driver is made of solid materials, has good shock and vibration resistance, and can adapt to harsh outdoor environments.
Instant Start: The LED driver starts up quickly and reaches maximum brightness without preheating.
Low-voltage operation: LED drivers generally use low-voltage DC power supply, which is highly safe and suitable for outdoor use.
Good optical performance: LED drivers can design different optical systems as needed to achieve directional lighting and reduce light pollution.
