Smart Wifi RGBCW Led Strip Controller
SMART RGBCW CONTROLLER
BS-WIZCV1224-048/RGBTW
The Smart Wifi RGBCW Led Strip Controller is a unique and revolutionary solution to easily control your LED light strips. It lets you to control the color, brightness, and mode of your lightstrips using your smartphone. The system is simple to set up and use, and the mobile software is available for both Android and iOS smartphones. If you enjoy smart home technology, this lightstrip controller is an excellent addition to your house because it allows you to automate your lighting according to your preferences and schedule. The WIZ lightstrip intelligent controller offers limitless options for altering your home with colorful and ambient lighting.
Smart RGBCW Led Strip Controller Features
1. 5 channel dimming approach using PWM：A RGBW controller is a device that allows you to control the color and brightness of RGB and white LED strips. The RGBCW controller goes beyond this functionality by allowing you to also control cold white and warm white LEDs.
2.Appropriate for both standalone and integrated use
3. Always the right mood: Having the brightest smart bulb makes it easy to tidy up the 2,000-piece unicorn puzzle that your daughter left on the living room floor. Having the most flexible smart bulb means you can instantly transition to a romantic ambiance later, after your daughter has gone to bed
4. Wi-Fi + Bluetooth dual protocol module that permits Bluetooth installation messages and WiZ cloud access over Wi-Fi network ：WiZ works with major smart home ecosystems worldwide, so you can control WiZ with your preferred system or device.
WIZ App Installation
1. Download it free by Google Play
2. Install by QR Code: use QR scan app to scan QR code, then download and install it.
3. Down it free in App store or Android store: App store search WIZ CN V2
Electrical Data
|
Item |
SmartStrip Controller WiZ RGBTW 12-24V |
|
Model No. |
BS-WIZCV1224-048/RGBTW |
|
Rated input voltage |
12…24Vdc |
|
Rated input current |
2A @ Max output power |
|
Max input power |
48W @ Max output power /@ Max Rated input voltage |
|
Rated output current |
2A max total ; |
|
Standby power |
<0.5W @ Rated input voltage |
|
ESD |
4KV @ HBM, 8KV @ air |
|
Dimming method |
PWM, 2KHz |
|
Dimming range |
0-100% |
|
Ambient temperature |
-20…+50ºC |
|
Tcase-life |
75ºC |
|
Lifetime |
50,000 hrs |
|
Mains switching cycles |
100,000 Cycles |
|
Connection |
Wi-Fi IEEE802.11 b/g, BLE 4.2 |
|
Audible noise |
<24 dB @ 5cm |
|
Ingress Protection |
IP20 |
|
Approval Marks |
CE-RED |
All specififications are typical and at 25 °C Tcase unless otherwise specifified.
RF Interface
|
Communication method |
Wifi + BLE |
|
Wifi Frequency |
2400-2483.5 Mhz (IEEE Std 802.11 b/g) |
|
Wifi Transmission power |
20dbm Max |
|
BLE Frequency |
2400-2483.5 Mhz |
|
BLE Transmission power |
3dbm Max |
|
Wifi channel |
1...13 |
Press Button
|
Press button |
Press 3 times to start pairing |
Wiring and Connections
Dimensions & Weight
|
Dimensions LxWxH |
195x45x15.5mm |
|
Color |
White |
|
Weight |
50 g |
Why choose wiz wifi rgb cct led strip controller?
1. Easy Installation: Wiz WiFi RGB CCT LED strip controllers are easy to install and can be done quickly.
2. App Control: The Wiz app allows you to control your LED strip from anywhere using your smartphone or tablet.
3. Versatility: The Wiz WiFi RGB CCT LED strip controller can be used with a variety of LED strip lighting brands and can control up to 2,500 LEDs.
4. Customization: The Wiz app allows you to customize your LED strip with over 16 million color options and brightness settings.
5. Energy Saving: The Wiz WiFi RGB CCT LED strip controller is energy efficient, saving you money on your electricity bill.
Our Advantages
1. Over 20 Years Manufacturer Since 2001
2. PHILIPS OEM Partner Since 2008
3. Authorized Signify OEM Channel Special Service Provider-Connected by WiZ,MasterConnect
4. National High-Tech Enterprice
5. ISO9001:2008 Quality Management
6. Break Through 50 Patents
7. CE, ROHS, ENEC, FCC, UL, CCC
